Force Dynamics 301 / 401cr — Commercial Motion Platforms
Large-range, high-fidelity motion with commercial-grade uptime. Deliver sustained g-force cues, continuous rotation (401cr), and real seat-of-the-pants driving feel.
301 from $72,300 · 401cr from $89,900
Request Pricing & InfoWhy 301 / 401cr for commercial use?
- Design philosophy: Built by racers to provide legitimate, high-quality feedback — not just “immersion.” Learn tracks faster, improve consistency, and engage customers with real g-load cues.
- Software support: ForceControl supports dozens of titles (iRacing, Assetto Corsa, rFactor 2, Project CARS, MSFS, DCS, etc.) with presets per title/car and ongoing updates.
- Build quality: Industrial servo systems and robust construction derived from factory automation — engineered for years of service in demanding venues.
- VR (for real): Motion-compensated VR so views stay level during large motions — no “swinging hammock” effect and reduced motion sickness.
Commercial bundle — ready to run
All 301 and 401cr systems ship RTR with Corbeau seat, Heusinkveld Sprint pedals, onboard PC, 5.1 audio, and triple-monitor display. Turnkey software loads and race-management available for sim centers and events.
Plan a commercial deploymentQuick specs
| 301 — 3-DOF platform | |
|---|---|
| Axes | Roll, Pitch, Heave |
| Motion Range | Roll ±25°, Pitch ±25°, Heave ±20 cm (±8″) |
| Slew Rates | Roll 60°/s, Pitch 60°/s, Heave 48 cm/s |
| Peak Accel. | Roll 572°/s², Pitch 286°/s², Heave 2.4 g |
| Footprint | 1.53 m × 2.14 m (5′ × 7′); height at rest ~1.83 m (72″) |
| Power | 120 VAC (18 A RMS*, 70 A peak) · 240 VAC optional |
| Passenger | Full performance 114 kg (250 lb); max 145 kg (320 lb) |
| 401cr — 4-DOF w/ continuous yaw | |
|---|---|
| Axes | Roll, Pitch, Heave, Yaw (continuous) |
| Motion Range | Roll ±25°, Pitch ±25°, Heave ±20 cm |
| Slew Rates | Roll 60°/s, Pitch 60°/s, Heave 48 cm/s, Yaw 105°/s |
| Peak Accel. | Roll 572°/s², Pitch 286°/s², Heave 2.4 g, Yaw 343°/s² |
| Working Envelope | Plan 244 cm × 244 cm (8′ × 8′), Elevation ~274 cm (9′) |
| Power | 120 VAC (20 A RMS*, 80 A peak) or 240 VAC (10 A RMS, 40 A peak) |
| Passenger | Full performance 114 kg (250 lb); max 145 kg (320 lb) |
* Branch circuit should use a thermal breaker due to high peak currents.
Pricing
- 301 motion simulator$72,300
- 401cr continuous rotation simulator$89,900
- Triple 27″ curved LCDIncluded
- Triple 32″ LCD$2,500
- Triple 32″ OLED$5,500
- HTC Focus 3 VR (with monitors)$2,100
- HTC Focus 3 VR (stand-alone)$1,100
Standard inclusions
- Force Dynamics Turnbox FFB w/ suede wheel, magnetic paddles, buttons & dials
- Heusinkveld Sprint pedals
- Onboard gaming PC
- 5.1 surround audio (12″ sub + satellites)
- Corbeau A4 seat (or similar)
- Vibration isolation feet (301) · Steel levelers (401)
- 120/240 VAC 50–60 Hz power
Popular options
- Remote E-stop switch & cable$175
- Heusinkveld Ultimate pedals (upgrade)$1,000
- Simagic DS-8X H-pattern shifter (mounted)$550
- Heusinkveld handbrake (mounted)$500
- MOMO D-shape 270 mm wheel (swap)N/C
- MOMO 320 mm wheel (swap)N/C
- Simucube Ultimate wheelbase*$2,800
- GSI GT-Max32 wheel rim$1,700
- GSI Hyper P1 wheel rim$1,850
- Thrustmaster Warthog HOTAS (mounted)$1,100
- 5/6-point harness$550
- Custom color$5,000
- Corbeau A4 seat — extended width$120
- Corbeau A4 seat — submarine belt slot$40
- MOMO containment racing seat (swap)$200
- 401 transport wheel & jack kit w/ ramps$1,455
- 301 transport wheel & jack kit w/ ramps$950
- Rubber bottomed levelers (non-marking)$150
- Toolkit (install & maintenance)$150
* Simucube Ultimate not recommended for high-volume retail use; GSI rim required.
Built for uptime
- Design life: Components sized for B-10 life of 5,000 hours; many platforms run well past this in the field.
- Construction: Case-hardened strut tubes, oversized ball screws, brushless motors with brakes, steel weldment frame, screened fans, filtered power entry, thermal breaker.
- Safety: Seat-belt/door interlocks, onboard & remote E-stop, redundant safety relay supervision; pause mode for controlled stops.
- CE & TUV certified
- Ambient 0–32 °C (32–90 °F)
- Avoid direct sun on enclosure
- Humidity 5–80% RH
Ordering & logistics
- Payment terms: 50% to order; 50% + shipping prior to shipment (FOB shipping point).
- Delivery (new builds): 301 ~8–10 weeks · 401cr ~12–14 weeks · Custom TBD (faster delivery sometimes possible; ask).
- Warranty: 1-year defective parts incl. standard shipping (wear parts, labor, expediting not included). Monitors/projectors per manufacturer.
- Crate dims (approx.): 301 — 1700 lb / 771 kg, 80″×73″×96″ · 401cr — 3500 lb / 1600 kg, 80″×73″×96″.
- Safety barrier: Required; keep public out of working envelope. Interlocked gate recommended.
- Venue support: Turnkey software loads, race-management, and layout guidance available.
Frequently asked questions
301 vs. 401cr — which should I choose?
Both deliver large-range, high-speed cues. Choose 401cr if your use-case benefits from continuous yaw (drift, rally, aviation-style rotation, advanced training, or premium venue differentiation).
Power requirements?
301: 120 VAC (18 A RMS*, 70 A peak) or 240 VAC optional. 401cr: 120 VAC (20 A RMS*, 80 A peak) or 240 VAC (10 A RMS, 40 A peak). Use thermal breakers due to peak draw.
Can you help with multi-rig layouts?
Yes — we coordinate space/egress, power/network planning, operations, and race-management to maximize throughput and guest experience.
